Von Duprin RX9875L-NL-03-F 3 26D LHR Von Duprin Mortise Exit Devices Satin Chrome

Details

• Device Functions: Device ships EO/DT/NL. Field selectable. For TP, K or L remove NL drive screw from device.
• Device Lengths: 3′ 2′ 4″ to 3′ (711 mm to 914 mm) door size 4′ 2′ 10″ to 4′ (864 mm to 1219 mm) door size
• Device centerline from finished door: 39-13/16″ (1011 mm) 39-11/16″ (1008 mm) with mullion
• Center case dimensions: 8″ x 2-3/4″ x 2-3/8″ (203 mm x 70 mm x 60 mm)
• Mechanism case dimensions: 2 1/4″ x 2 1/4″ (57 mm x 57 mm)
• Projection: Pushbar neutral 3-13/16″ (97 mm); Pushbar depressed 3-1/16″ (78 mm)
• Fasteners & sex bolts (SNB): Includes screw pack for 1-3/4″ (44 mm) and 2-1/4″ (57 mm) thick metal or wood doors.

Color

Satin Chrome

Color Code

626/US26D

Fire Rated

Yes {Variable}

Origin

USA

BAA Qualified

Yes

Package Height

10.5

Package Length

37

Package Volume

1942.5

Package Width

5

Handing

Left Hand Reverse

Product Overview

Grade 1 Mortise Exit Bar for Wood Doors, 36″ Device, Fire Rated, Night Latch Function, 03 Lever with Escutcheon Trim, Request to Exit Switch, Less Dogging, Satin Chrome Finish, Field Reversible

9875/9975 Mortise lock device for all types of single or double doors, UL listed for panic exit hardware. Fits stock hollow metal doors with 86 cutout and door stiles as narrow as 4 34″ (121mm). The 7500 Mortise lock is equipped with a 34″ (19mm) anti-friction latch bolt which is field reversible without removing the lock from the door. It has a non-handed auxiliary bolt for deadlocking and a faceplate with an adjustable bevel.

Fire exit mortise lock devices with a smooth mechanism case.

The 9875 Series is for all types of single or double doors and is UL listed for panic exit hardware. Devices are ANSI A156.3 2008 Grade 1. Fits stock hollow metal doors with 86 cutout and door stiles as narrow as 4-3/4″ (121mm).
