Von Duprin RX9875K-BE 4 643E Mortise Exit Devices Aged Bronze

Details

• Device Functions: Device ships EO/DT/NL. Field selectable. For TP, K or L remove NL drive screw from device.
• Device Lengths: 3′ 2′ 4″ to 3′ (711 mm to 914 mm) door size 4′ 2′ 10″ to 4′ (864 mm to 1219 mm) door size
• Device centerline from finished door: 39-13/16″ (1011 mm) 39-11/16″ (1008 mm) with mullion
• Center case dimensions: 8″ x 2-3/4″ x 2-3/8″ (203 mm x 70 mm x 60 mm)
• Mechanism case dimensions: 2 1/4″ x 2 1/4″ (57 mm x 57 mm)
• Projection: Pushbar neutral 3-13/16″ (97 mm); Pushbar depressed 3-1/16″ (78 mm)
• Fasteners & sex bolts (SNB): Includes screw pack for 1-3/4″ (44 mm) and 2-1/4″ (57 mm) thick metal or wood doors.

Color

Aged Bronze

Color Code

643E/US11E

Fire Rated

No

Origin

USA

BAA Qualified

Yes

Package Height

10.5

Package Length

49

Package Volume

2572.5

Package Width

5

Product Overview

Grade 1 Mortise Exit Bar for Wood Doors, 48″ Device, Passage Function, Knob with Escutcheon Trim, Request to Exit Switch, Hex Dogging, Aged Bronze Finish, Field Reversible

9875/9975 Mortise lock device for all types of single or double doors, UL listed for panic exit hardware. Fits stock hollow metal doors with 86 cutout and door stiles as narrow as 4 34″ (121mm). The 7500 Mortise lock is equipped with a 34″ (19mm) anti-friction latch bolt which is field reversible without removing the lock from the door. It has a non-handed auxiliary bolt for deadlocking and a faceplate with an adjustable bevel.

Fire exit mortise lock devices with a smooth mechanism case.

The 9875 Series is for all types of single or double doors and is UL listed for panic exit hardware. Devices are ANSI A156.3 2008 Grade 1. Fits stock hollow metal doors with 86 cutout and door stiles as narrow as 4-3/4″ (121mm).
