Sargent 8710J RHR 10B Exit Device Dark Oxidized Satin Bronze Oil Rubbed

Details

• Door Types: Wood or metal 1-3/4″(44mm) Thick Door; Over 1-3/4″ to 2-1/4″ specify thickness and order as a 31- prefix. 4-1/2″ (114mm) minimum stile with trim and 3-1/2″ (44mm) minimum stile without trim
• Door Widths:E Rail – 24″ to 32″ (61cm to 81cm) No cutting required for 32″ door; F Rail – 33″ to 36″ (84cm to 91cm) No cutting required for 36″ door; J Rail – 37″ to 42″ (94cm to 107cm) No cutting required for 42″ door; G Rail – 43″ to 48″ (110cm to 122cm) No cutting required for 48″ door

Grade

Grade 1

Hand

RHR

Color

Dark Oxidized Satin Bronze Oil Rubbed

Color Code

613/US10B

Door Thickness

1-3/4″ to 2-1/4″

Door Width

37 In. to 42 In.

Device Length

42 In.

Door Height

84 In.

Fire Rated

No

Origin

USA

BAA Qualified

Yes

Package Height

6″

Package Length

38″

Package Volume

1710

Package Width

7.5″

ANSI Number

1

Device Type

Surface Vertical Rod

Includes Trim

No

Mechanical Function

Exit Only

Minimum Stile Size

4-1/2″ with Trim, 3-1/2″ without Trim

Package Qty

1

Physical Appearance

Wide Stile Pushpad

Strike Bottom

624

Strike Top

646

Base Material

Bronze

Door Material

Metal or Wood

Handing

Right Hand Reverse

Rail Size

J Rail for 37″ to 42″ door widths

Product Overview

Surface Vertical rod Exit Device, Exit Only, 42″, Oil Rubbed Bronze

The Sargent 80 Series exit devices are ideal for environments that require strong and durable security solutions that will last the life of the building. Available in rim, mortise, surface vertical and concealed vertical rod configurations, these exit devices easily exceed ANSI/BHMA Grade 1 requirements for cycle and strength. With modular construction and few moving parts, the 80 Series devices are maintenance-free and provide unsurpassed security for any facility. Plus, options are available for unique applications including delayed egress, alarmed exit and electric latch retraction making these exit devices the go-to product in your building.

Has two point latching and is adjustable through the center case.

Part of Sargent’s full line of exit devices that provide the best combination of simplicty, strength, durability, aesthetics, and innovation. The top and bottom latchbolt projection is adjustable through the center case.
