No-Mortise Hinges With Finial TipSmall

Details

• Hinge requires no mortising to install.
• Leaves only a 1/16″ gap.
• Tight pins with decorative finial tip.
• Joint length means distance along hinge pin. Does not include finials.
• The “Width Closed” dimension means the width of the hinge leaf (as shown in the photo, above), not including the hinge barrel.

Small

• Fits This Panel Thickness- 5/8″ to 13/16″
• Joint Length- 2″
• Overall Length- 3″
• Width Closed- 11/16″
• Four x #4 flat head wood screws

Medium

• Fits This Panel Thickness- 11/16″ to 7/8″
• Joint Length- 2-1/2″
• Overall Length- 3-1/2″
• Width Closed- 3/4″
• Five x #5 flat head wood screws

Large

• Fits This Panel Thickness- 15/16″ to 1-1/4″
• Joint Length- 3″
• Overall Length- 4-3/8″
• Width Closed- 1″
• Six x #5 flat head wood screws
