No-Mortise Hinge1-1/2″

Details

• Requires no mortising to install.
• Leaves only a 1/16″ gap.
• Tight pins.
• The “Leaf Width” dimension listed below is the distance from the edge of the hinge leaf to the edge of the hinge barrel. Joint length is the distance along the hinge pin or hinge pin barrel.

Sizes (By Joint Length)

1-1/2″ Size

• Fits This Panel Thickness: 1/2″ to 5/8″
• Joint Length: 1-1/2″
• Leaf Width: 9/16″
• Four x #4 flat head wood screws (not included)

2″ Size

• Fits This Panel Thickness: 5/8″ to 13/16″
• Joint Length: 2″
• Leaf Width: 5/8″
• Four x #4 flat head wood screws (not included)

2-1/2″ Size

• Fits This Panel Thickness: 11/16″ to 7/8″
• Joint Length: 2-1/2″
• Leaf Width: 11/16″
• Five x #5 flat head wood screws (not included)

3″ Size

• Fits This Panel Thickness: 1″ to 1-1/4″
• Joint Length: 3″
• Leaf Width: 1″
• Six x #5 flat head wood screws (not included)
