Corbin Russwin N910ET 630 RHR Right Hand Reverse Passage Newport Lever and Escutcheon Exit Trim Satin Stainless Steel Finish

Details

Trim Design

Escutcheon with Lever

Color

Satin Stainless Steel

Hand

Right Hand Reverse

Fire Rated

No

Application

x910 – Passage

Package Qty

1

Trim Type

Passage Lever

Color Code

630/US32D

Finish

Satin Stainless Steel

Handing

Right Hand Reverse

Function

10-Passage

Finish Description

Satin Stainless Steel

Lever Style

N-Newport

Product Type

Exit Device Trim

Series

ED5000 Series Trim

Device Type

Rim, SVR or CVR

Trim Plate Height

10-1/4 Inch

Device Trim ANSI Function

1-4

Manufacturer Parent

Assa Abloy

For Use With

ED5000 Series Exit Devices

Sub-Series

EDT_Device_Trim_corbin_russwin_6

Trim Style

ET Escutcheon with Lever

ADA Compliant

No

Trim Plate Thickness

7/8 Inch

Lever Length-Inches

4-13/16 Inch

Trim Plate Width

3 Inch

Device Trim Function

Latch Bolt Retracted by Knob or Lever

Function Family

Passage Exit Device Trim

Product Projection

3-1/16 Inch

Features

Free Wheeling Vandal-Resistant Design; Beveled Edges; Through-Bolted to Exit Device

Product Material

Lever: Cast; Escutcheon: Forged

Warranty

5 yr limited

Cylinder Type Used

Rim

Finish Family

Stainless Steel

Product Overview N9 Newport Lever Escutcheon Trim Design Features:

• Escutcheon – Forged

• Lever – Cast

Functions:

• N910ET – Passage

• N950ET – Dummy

• N955ET – Classroom

• N959ET – Storeroom

Finishes:

• 630 – Satin Satinless Steel

• 626 – Satin Chrome

• 613 – Oil Rubbed Bronze

• 612 – Satin Bronze

• 605 – Bright Brass
