Circuit breaker | C60N 3P 6A C

Details

Technical data

range of product

C60

range

Multi 9

product name

C60

product or component type

Miniature circuit-breaker

device short name

C60N

device application

Distribution

poles description

3P

number of protected poles

3

[In] rated current

6 A at 30 C

network type

AC

trip unit technology

Thermal-magnetic

curve code

C

breaking capacity

20 kA Icu at 130 V AC 50/60 Hz conforming to EN/IEC 60947-2
10 kA Icu at 230…240 V AC 50/60 Hz conforming to EN/IEC 60947-2
3 kA Icu at 400…415 V AC 50/60 Hz conforming to EN/IEC 60947-2
6000 A Icn at 230/400 V AC 50/60 Hz conforming to EN 60898
15 kA Icu at 60 V DC 1P conforming to EN/IEC 60947-2

suitability for isolation

Yes conforming to IEC 60947-2

network frequency

50/60 Hz

[Ue] rated operational voltage

230…240 V AC 50/60 Hz
400…415 V AC 50/60 Hz
130 V AC 50/60 Hz
230/400 V AC 50/60 Hz

magnetic tripping limit

5…10 x In

[Ics] rated service breaking capacity

15 kA conforming to EN/IEC 60947-2 – 130 V AC 50/60 Hz
7.5 kA conforming to EN/IEC 60947-2 – 230…240 V AC 50/60 Hz
6000 A conforming to EN 60898 – 230/400 V AC 50/60 Hz
2.25 kA conforming to EN/IEC 60947-2 – 400…415 V AC 50/60 Hz

limitation class

3 conforming to EN/IEC 60947-2

contact position indicator

Yes

control type

Toggle

local signalling

ON/OFF indication

mounting mode

Clip-on

mounting support

35 mm symmetrical DIN rail

9 mm pitches

6

height

81 mm

width

54 mm

depth

73 mm

net weight

0.36 kg
